Professional external waterproofing for floor-level doors, windows and structural thermal upstands, including suitable connections to building waterproofing in areas close to ground level.
The blaugelb FLK Waterproofing System has been independently assessed by MPA Braunschweig for specified floor-level window and door connections. It provides a documented approach to waterproofing these critical building details.
Available in two versions: FLK Liquid 7 kg for larger waterproofing areas and FLK Liquid Corner 3.5 kg for localised detailing of corners, grooves and difficult-to-access areas.
blaugelb FLK is a one-component, polyurethane-based liquid waterproofing product designed to form flexible, waterproof connections on suitable building substrates.
The products are particularly useful for external waterproofing details around entrance doors, floor-to-ceiling windows, sliding doors and thermal threshold supports.
Waterproofing at floor-level doors and windows requires particular attention to the connection between the building element, the supporting substrate and the external building waterproofing.
The blaugelb FLK Waterproofing System has been independently assessed by MPA Braunschweig for specified floor-level window and door connections, including applications involving structural thermal upstands.
The assessment considers relevant requirements for connections associated with waterproofing under DIN 18531 and DIN 18533.
This provides documented technical evidence for the specified system applications when installed in accordance with the manufacturer's relevant instructions and assessed construction details.
| Product | Application | Packaging |
|---|---|---|
| FLK Liquid | Larger waterproofing areas and suitable horizontal or vertical connections. Follow the specified manufacturer system build-up. | 7 kg |
| FLK Liquid Corner | Fibre-reinforced waterproofing for localised corners, grooves and complex details. | 3.5 kg |
FLK waterproofing is the final external sealing step in a properly designed door threshold installation. It complements TRIOTHERM+ structural insulation upstands and Power FIX adhesive, providing protection at critical external connections.
Substrates must be sound, stable, clean and free from dust, loose particles, grease and other substances that may impair adhesion.
Observe the manufacturer's requirements for substrate preparation, compatibility and preliminary adhesion testing.
At corners and junctions around TRIOTHERM+ structural door upstands, WISA Out Plus sealing tape can be used as an additional local reinforcement detail before applying FLK.
A 60 mm wide tape is generally sufficient for this purpose, provided it offers suitable coverage of the particular corner or junction.
This is a practical application suggestion for local junction detailing. It does not imply that WISA Out Plus forms part of the independently assessed FLK system construction. Verify suitability and compatibility for the specific application.
Both the TRIOTHERM+ surface and the adjoining building substrate must be at least 3°C above the calculated dew point before FLK is applied.
Check the actual conditions at the installation location, including the surface temperatures of both materials.
Use our online calculator to check the dew point and the required minimum surface temperature.
Open FLK Dew Point Calculator →
The calculator provides general guidance. Always check actual site conditions and follow the manufacturer's current technical instructions.
Stir the product thoroughly before use and apply according to the current manufacturer's technical data sheet and application instructions.
Material consumption, number of coats, reinforcement requirements and application method depend on the selected product and waterproofing detail.
Do not apply to surfaces with condensation or standing surface moisture.
| Manufacturer brand | blaugelb |
| Product type | One-component liquid waterproofing |
| Material basis | Polyurethane-based |
| FLK Liquid packaging | 7 kg |
| FLK Liquid Corner packaging | 3.5 kg |
| Processing temperature | +5°C to +40°C |
| Minimum relative humidity | 30% |
| Minimum stirring time | 2 minutes |
| Dew point requirement | Surface temperature at least 3°C above dew point |
| Rainproof after | Approx. 60 minutes* |
| Recoatable after | Approx. 8 hours* |
| Curing time | Approx. 2 days* |
| Colour | Traffic grey |
*Indicative values at 23°C and 50% relative humidity. Actual processing and curing times depend on site conditions. Consult the relevant current Technical Data Sheet for product-specific requirements.
The blaugelb FLK Waterproofing System has been evaluated by MPA Braunschweig in expert assessment No. 1203/540/22 for specified construction details involving floor-level building elements.
The assessment applies to the investigated system configurations and must not be interpreted as blanket approval of all possible installation methods, substrates or reinforcement materials.
Substrate suitability, reinforcement requirements, application thickness and material consumption must be determined according to the applicable manufacturer's instructions and the intended waterproofing detail.
These products are designated for professional/trade use in the manufacturer's documentation.
Official manufacturer documentation. Please select the documents corresponding to the FLK product you are using.
Technical documents are linked directly to the manufacturer's website. The independent MPA assessment is referenced under Technical Data; the scope of the assessment is limited to its investigated system configurations.
